Electric height adjustable washbasin system with mirror and lighting – DESIGNLINE 417-0
Product Overview Electric Height Adjustable Washbasins
- Description
- Brand
Description
For washbasin
Max weight: 40kg
Max width: 670mm
Max depth: 600mm
Basin centre-to-centre fixings: 280mm
Total depth
120mm
Type of lift
Electric steplessly height-adjustable washbasin module with mirror and lighting
Width
715mm
Installation
Wall-mounted
Height adjustment
250mm
Speed level
18mm/s
Lifting force
100kg
Electrical connection
Plug to 230 V, max 1.5A
Lightning
Lighting ramp: Solid oiled oak with 3 × recessed spotlights (connected to external power switch)
Spotlights: LED 3W, 3000K
Transformer: 230V
IP-class
IPX4
Safety
Safety switch stops the descent of the basin if it comes into contact with an obstruction
Material
Back panel: Plywood coated with high-pressure laminate
Mirror: 1000×600×4 mm in silver-backed float glass with ground edges incl. mirror clips
Mounting cover: White plastic
Plumbing connections
Flexible water hoses and drain hose with water trap
Warranty
2 years Warranty
This product is covered by a 2-year warranty against manufacturing defects.
Dimensions
Functions and Advantages
- Width: 71.5cm
- Depth: 12.0cm
- Mirror and lighting move in tandem with the basin
- Easy-to-use controller
- Basin centre-to-centre fixings: 28cm
– Mirror and lighting (3 spotlights)
