Wall

103 mm

Manually adjustable by 300 mm in intervals of 25 mm
(700-1000 mm excl. top board)
A built-in gas spring facilitates height adjustment:
Pull out the locking pin, adjust the height with the help of the gas spring. Lock the position with the locking pin.

100 kg

Ready-mounted worktop incl. wall-mounted brackets

576 – 606 mm from wall (Incl. front)

Frame:
Aluminum
Cover panels for covering installations under the worktop:
12 mm white melamine. Several colours can be offered upon request.
Fronts:
White lacquered aluminum. Several colours can be offered upon request.
Top board:
30 mm worktop in high pressure laminate. Post-shaped front edge. Several colours can be offered upon request.

2 pcs, width = width of the lift -10 mm, height 438 mm,
thickness 12-20 mm

Width = width of the lift

565-630 mm (15 mm shallower than worktops on fixed cabinets)

5 mm

15 mm

From 700 mm above floor (alternatively all the way down to the floor)

Bracket for fronts and top board
